Swaraj 744 FE
swaraj 744 FE
Swaraj 744 FE is a 33.55 – 37.28 kW (45-50hp) category tractor which provides real value for money to its owners. It is fitted with a powerful & fuel efficient 3-cylinder water-cooled engine. It comes with multi speed forward and reverse PTO which makes it highly fuel efficient on PTO driven applications like alternator thresher and reaper. The tractor is equipped with host of features like power steering, dual clutch, DCV and adjustable front-axle. Overall, a powerful all-rounder and an excellent performer.
At a Glance
No. Of Cylinder : 3
Power Category : 33.55–37.28 kW (45-50 HP)
Engine : 3136 cm3
Brakes : Dry Disk brakes / OIB
PTO r/min : 1000 r/min or 540 r/min, CR-PTO
Provides high r/min on PTO even at low engine r/min, hence saves fuel on applications like alternator ,thresher & genset. Hence more fuel savings
Ease of turning – operator comfort
Ease of operation for operating external hydraulic implements like reversible M.B plough & Dozer etc.
Powerful 3 Cylinders Water Cooled Engine
Uninterrupted PTO operation - More output
Easy adjust of front track - Suitable for inter cultivation like potato farming
Better braking efficiency - Less maintenance - Longer life
Model RB-30 TR
Power: 33.55 – 37.28 kW (45-50 HP)
Type 4 - Stroke, Direct Injection, Diesel Engine
No. of Cylinders 3
Bore and Stroke 110 X 110 mm
Displacement 3136 cm3
Rated Engine Speed 2000 r/min
Air Cleaner 3- Stage Oil Bath Type
Cooling System Water Cooled with No loss tank. Oil Cooler for engine oil
Clutch Standard Single dry disc friction plate - 305 mm dia.
Clutch Optional Dual Clutch
No. of Gears 8 Forward, 2 Reverse speeds
Forward 3.1 to 29.2
Reverse 4.3 & 14.3
PTO Speed: Standard 1000 r/min
PTO Speed: Optional 540 r/min , CR- PTO with Multi speeds
Brake type: Stanrad Dry Disc type Brakes
Brake type: Optional Oil Immersed Brakes
Standard Mechanical Steering with Heavy Duty single drop arm for better maneuverability & comfort to operator.
Optional Power Steering
Live Hydraulics A) Position control: To hold lower links at any desired height. B) Automatic draft control :To maintain uniform depth c) Mix Control : For optimum field output
Lifting Capacity 1700 kg at lower link ends.
Linkage 3 point linkage suitable for Category-I & II type implement pins.
Front Tyre Standard 6.00 x 16
Rear Tyre Standard 13.6 x28
Front Tyre /Rear Tyre Optional 7.50 x16 / 14.9 X 28
Electricals & Electronics
Electricals 12 V, 88 Ah. Battery Starter motor & Alternator
Instruments Engine r/min cum hour meter with direction indicators, Fuel Gauge, Ammeter, and Water Temp. Gauge & Oil Pressure Indicator.
Weights & Dimensions
O.A. Length 3440 mm
O.A. Width 1730 mm
O.A. Height 2275 mm
Wheel Base 1950 mm
Min. Ground Clearance 400 mm
Weight of Tractor 1990 kg
Wheel Track Front 1300 mm
Wheel Track Rear 1350 mm (with 13.6*28 tyre type)
